Product image is representative; revision or series may vary. Contact us to request a specific version.
HC-SFE52K
The HC-SFE52K motor by Mitsubishi is a MELSERVO middle-inertia and middle-capacity servo motor. It operates with 500 Watts of rated output power, and it operates on a three-phase AC power supply with an input voltage rating of 126 Volts AC and a standard current rating of 3.2 Amperes. Its compact design makes it easy to install. The HC-SFE52K servo motor has a shaft with a keyway and a key, an encoder, and an IP65 enclosure.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for HC-SFE52K
| Manufacturer | Mitsubishi |
|---|---|
| Product Type | Servo Motor |
| Product Line | MELSERVO HC |
| Part Number | HC-SFE52K |
| Weight | 3.00 lbs (1.36 kg) |
| Voltage Type | 3-phase AC Voltage |
| Output Power Rating | 500 Watts |
| Input Voltage | 126 Volts AC |
| Current Rating | 3.2 Amperes |
| Maximum Current | 9.6 Amperes |
| Rated Speed | 2000 RPM |
| Maximum Speed | 3000 RPM |
| Shaft Type | Keyway Shaft with Key |
| Encoder | Supported |
| Encoder Resolution | 10,000 Pulses/Rev |
The HC-SFE52K motor is a servo motor that was manufactured by Mitsubishi Electric in the MELSERVO series. It is a medium-inertia and medium-capacity type of servo motor. The HC-SFE52K motor has an output power rating of 500 Watts. The HC-SFE52K motor can operate on a three-phase AC power supply, and it requires an input voltage rating of 126 Volts AC to operate. The HC-SFE52K servo motor has a standard current rating of 3.2 Amperes and a maximum current rating of 9.6 Amperes. This servo motor is easy to install and integrate into existing systems without any extensive modifications because of its compact size and voltage requirements. The HC-SFE52K servo motor can be used in robotics, CNC machine tools, or automated assembly line applications. The speed, torque, and position of the HC-SFE52K servo motor can be controlled by a compatible Mitsubishi servo amplifier or servo drive. The HC-SFE52K servo motor’s rated torque is 2.39 N-m while its maximum torque rating is 7.16 N-m. Additionally, the HC-SFE52K servo motor’s standard rated speed is 2000 RPM in most applications. It can also operate at 3000 RPM of maximum speed or at 3450 RPM of permissible instantaneous speed in some applications. The HC-SFE52K servo motor’s shaft includes a keyway and a key. This servo motor has no electromagnetic brake. Its speed and position detector device is a encoder with a resolution rating of 10,000 pulses per revolution. The HC-SFE52K servo motor has Class F insulation, an IP65-rated enclosure that is self-cooled and totally enclosed, and an operating temperature range from 0 to 40 degrees Celsius.
