HC-SFS202K
The HC-SFS202K AC servo motor that was manufactured by Mitsubishi Electric in the MELSERVO series. Its rotational speed ratings include 2000 RPM of rated speed and 2500 RPM of maximum speed. This servo motor delivers 9.55 Nm of rated torque and 28.5 Nm of maximum torque for ensuring stability and efficiency in industrial tasks. Its compact design, IP65 protection rating, and operating temperature range (0 to 40 degrees Celsius) make it versatile and suitable for use in various general-purpose industrial applications.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for HC-SFS202K
| Manufacturer | Mitsubishi |
|---|---|
| Product Type | AC Servo Motor |
| Product Line | MELSERVO HC |
| Part Number | HC-SFS202K |
| Weight | 12.00 lbs (5.44 kg) |
| Series | MELSERVO |
| Rated Speed | 2000 RPM |
| Standard Torque | 9.55 Nm |
| Maximum Torque | 28.5 Nm |
| Maximum Speed | 2500 RPM |
| Rated Current | 11 Amps |
| Maximum Current | 33 Amps |
| Output Power | 2 kW |
| Shaft Type | Keyway, No Key |
| Operating Temperature | 0°C to +40°C |
| Storage Temperature | -15°C to +70°C |
The HC-SFS202K servo motor is an AC servo motor designed for general-purpose applications in a variety of non-hazardous industrial environments. It is manufactured by Mitsubishi Electric, and it is a middle inertia and middle capacity servo motor from the Mitsubishi MELSERVO series. It supports reliable performance and operates at 2000 RPM of rated speed and 2500 RPM of maximum speed. The HC-SFS202K servo motor also has a rated torque value of 9.55 Nm and a maximum torque value of 28.5 Nm. As a result, the HC-SFS202K servo motor can deliver a steady and robust torque output that is suitable for various applications and tasks. The dimensions of the HC-SFS202K servo motor include a net height of 230 mm, a net width of 176 mm, and a net depth of 224 mm, and it supports a 176 x 176 mm flange mounting option. Additionally, the HC-SFS202K servo motor supports speed and position detection with its encoder. The encoder has a rated resolution of 131072 pulses per revolution. The HC-SFS202K servo motor has an IP65 ingress protection rating, and it is protected from significant amounts of dust and moisture. Moreover, it can operate effectively at temperatures ranging from 0°C to +40 °C, and it is suitable for storage at temperatures between -15°C and +70 °C. The HC-SFS202K servo motor has a maximum current rating of 33 A, and its standard current rating is 11 A. The output power rating of the HC-SFS202K servo motor is 2 kilowatts. The HC-SFS202K servo motor has a shaft with a keyway, but no key.
