Product image is representative; revision or series may vary. Contact us to request a specific version.
MR-J2S-60A
The MR-J2S-60A is a servo drive designed for motion control by Mitsubishi Electric. Operating via a power supply rated at 200 to 230 volts AC three-phase or 230 volts AC single-phase, this device ensures smooth and accurate movement. Its Sinusoidal PWM control system and built-in dynamic brake allow precise speed control and quick stopping. With a high-speed frequency response of 550 Hz, it handles rapid changes. The encoder-based positioning feedback delivers precise positioning, and torque control accepts commands up to ±8VDC.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for MR-J2S-60A
| Manufacturer | Mitsubishi |
|---|---|
| Product Type | Servo Drive/ Amplifier |
| Product Line | MELSERVO MR-J2 |
| Part Number | MR-J2S-60A |
| Weight | 2.56 lbs (1.16 kg) |
| Brand Name | Mitsubishi Electric |
| Series | MR-J2S |
| Power Supply (Voltage/Frequency) | 3-phase 200-230VAC, 50/60Hz; 1-phase 230VAC, 50/60Hz |
| Permissible Voltage Fluctuation (3-phase) | 170-253VAC |
| Control System | Sinusoidal PWM control/current control system |
| Dynamic Brake | Built-in |
| Speed Frequency Response | 550 Hz or more |
| Maximum Input Pulse Frequency (Position Control Mode) | 500 kpps (differential receiver), 200 kpps (open collector) |
| Positioning Feedback Pulse | 131072 pulses/revolution (encoder resolution) |
| Positioning Complete Width Setting | 0 - ±10VDC |
| Torque Command Input (Torque Control Specifications) | 0-±8VDC |
| Torque Limit (Speed Control Mode) | Set by parameters or external analog input (0-±10VDC) |
| Structure | Self-cooling, open (IP00) |
Part number MR-J2S-60A is a servo drive designed for precise motion control applications and driving electric motors. This device has been designed and manufactured by Mitsubishi Electric. It operates on a power supply of 3-phase 200-230V AC, 50/60 Hz, or 1-phase 230V AC, 50/60 Hz. The permissible voltage fluctuation is between 170-253V AC for 3-phase operation. In addition to its power ratings, the control system uses Sinusoidal Pulse Width Modulation (PWM) and current control to achieve accurate and smooth motion. The servo drive also features a built-in dynamic brake for quick-stopping capability. Aside from that, the speed frequency response of the MR-J2S-60A is an impressive 550 Hz or more, enabling rapid speed changes. In position control mode, it can process up to 500 kpps with a differential receiver or 200 kpps with an open collector for maximum input pulse frequency. At the same time, positioning feedback is achieved through an encoder, providing a high resolution of 131072 pulses per revolution of the servo motor. The positioning complete width can be set within the range of 0 - ±10V DC. For torque control, the servo drive accepts torque command inputs in the range of 0-±8V DC, with a maximum torque capacity. The torque limit can be set by parameters or an external analog input in the range of 0-±10V DC. In addition, the MR-J2S-60A is self-cooling and has an open (IP00) structure. This means it does not offer protection against dust or water ingress, making it suitable for use in controlled environments.
