C200H-OV001
The C200H-OV001 is a versatile voice module by Omron, designed to function as a special I/O module within the C200H series. This module supports up to 60 distinct messages and allows for flexible message lengths of 32, 48, or 64 seconds, with a refresh time of just 4.5 milliseconds.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for C200H-OV001
| Manufacturer | Omron |
|---|---|
| Product Type | Voice Module |
| Product Line | C200H |
| Part Number | C200H-OV001 |
| Weight | 1.00 lbs (0.45 kg) |
| Special I/O Module | Yes |
| Maximum Number of Supported Messages | 60 Messages |
| Switchable Message Length Options | 32, 48, and 64 Seconds |
| Refresh Time | 4.5 Milliseconds |
| Mixing Switch | Included |
| DIP Switches | Included |
| Backplane Connector | Included |
| LED Indicators | Included |
| Input Jack | Included |
| Output Jack | Included |
| RS-232C Port | Included |
| Sentence Mode | Supported for individual complete messages |
| Phrase Mode | Supported for combined messages |
| Recording Options | Microphone and magnetic tape |
The Omron C200H-OV001 voice module is integral for applications requiring audio output in industrial contexts. It is classified as a special I/O module, enabling seamless integration into the C200H series systems. This device can handle a maximum of 60 messages, with the added flexibility of configuring message lengths at 32, 48, or 64 seconds. Furthermore, its refresh capability of 4.5 milliseconds ensures rapid message playback.
For user convenience, the module includes a mixing switch and is equipped with DIP switches to adjust settings easily. The backplane connector facilitates installation, while LED indicators provide visual feedback on the module's status. Both input and output jacks are integral features that allow for straightforward connections. Communication with other devices is achieved through the included RS-232C port.
The C200H-OV001 supports unique modes for message playback. In sentence mode, entire messages are played back as complete units, whereas phrase mode allows for the combination of messages for extended communication needs. Users have the option to record messages utilizing either a microphone or magnetic tape, adding to the versatility of this module in various applications.
