Omron CJ1 CJ1M-CPU12

CJ1M-CPU12

|
Need a Specific Revision?

The Omron CJ1M-CPU12 CJ1M CPU module is a CPU Unit that has no built-in I/O. It can support 320 I/O points that are not built in. The CJ1M-CPU12 module has a user program memory capacity of 10K steps and a data memory capacity of 32K words. It is also equipped with 704 KB of flash memory (unit version 4 or later), and it consumes 0.58 A of current at 5 V DC from a power supply unit.

$845
Ships Today
1 in stock
Available
Request a quote
Fast response
Available
Request a quote
Fast response
$450
Ships Today
1 in stock
Ships Today.
In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with DO Supply's 2-year warranty.
Learn more
  • Warranty

    We sell industrial automation parts backed by our 2-year DO Supply Warranty.

  • Shipping

    Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.

  • Payment Methods

    AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.

  • Repairs & Exchanges

    Repairs and exchanges are available for all automation products.

  • Reseller Options

    Drop shipping, blind shipping, and account shipping with no extra fees.

Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for CJ1M-CPU12

Module Type:CPU Unit
Built-in I/O:None
Supported I/O Points:320
User Program Memory:10K steps
Data Memory:32K words
Interrupt Inputs:2 inputs
PWM Output Points:None
Maximum Subroutine Number:1,024
Maximum Jump Number for JMP Instruction:1,024
Function Blocks: Maximum No. of Definitions:128
Function Blocks: Maximum No. of Instances:256
Flash Memory:704 kbytes (Unit version 4 or later)
Current Consumption (Supplied by Power Supply Units):0.58 A at 5 V DC
Unit Width:31 mm
Weight:120 g max.
Request a Repair

The Omron CJ1M-CPU12 module is a robust Bulletin CJ1M CPU module that does not include built-in I/O channels but offers extensive capabilities for automation tasks. It can support 320 I/O points that are not built into it, and these I/O points enable it to handle multiple input and output devices efficiently. With 10K steps of user program memory and 32K words of data memory, the CJ1M-CPU12 CPU module supports complex programming tasks and data manipulation. The CJ1M-CPU12 CPU module does not support extended data memory. It supports 2 interrupt inputs, and it can promptly respond to critical events. The CJ1M-CPU12 CPU module does not have PWM output points, but it can support a maximum subroutine number of 1024 and a maximum jump number of 1024 for its JMP instruction. The unit supports a maximum of 128 function block definitions and 256 function block instances, and it supports modular programming for various applications. The CJ1M-CPU12 CPU module is equipped with 704 KB of flash memory (unit version 4 or later), ensuring ample storage for program data. Its current consumption rating is 0.58 A at 5V DC from a power supply unit. The CJ1M-CPU12 CPU module supports an RS-232C connector (Plug: XM2A-0901, Hood: XM2S-0911-E) as a standard feature. This CPU is compact and lightweight with a unit width of 31 mm and a weight of 120 g. It was designed to be easy to install in an Omron CJ series programmable controller system. Up to nine CJ1M-CPU12 CPU modules can be installed on a CPU rack in an Omron CJ series programmable controller.
