Omron CJ1 CJ1W-NC214

Product image is representative; revision or series may vary. Contact us to request a specific version.

CJ1W-NC214

|
Need a Specific Revision?

The Omron CJ1W-NC214 is an exactingly engineered position control unit that may be used for a range of automation and control applications. It is trustworthy and effective. This Omron product is excellent for installations with limited space because of its small 90, 51, and 65 mm (H x W x D) dimensions. It doesn't add extra weight to the system because its maximum weight is only 170g. Its operational temperature range, which spans 0 to 55 °C, attests to its consistent performance even amid changing climatic factors.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for CJ1W-NC214

ManufacturerOmron
Product LineCJ1
Part NumberCJ1W-NC214
Weight10.00 lbs (4.54 kg)
TypePosition Control Unit
Power supply voltage5 VDC (unit)
Allowable power supply voltage range21.6 to 26.4 VDC (external power supply)
Internal current consumption5 VDC, 270 mA maximum
Current consumption of external power supply24 VDC, NC214 13 mA maximum, NC234 44 mA maximum
Ambient operating temperature0 to 55 °C
Mounting positionCJ-series CPU Rack or CJ-series Expansion Rack
Maximum number of units per rack5 units
Maximum number of units per CJ system20 units (when up to 3 expansion racks are connected)
Occupied unitNo. 2
Applicable standardscULus, EC directives
Request a Repair

Omron created the CJ1W-NC214 Position Control Unit as a tool for use in situations needing precision control. It operates at a power supply voltage of 5 VDC (unit) when using its internal power supply, and an acceptable power supply voltage range for external power supplies is 21.6 to 26.4 VDC. The maximum internal current consumption at 5 VDC is 270 mA. However, the maximum external current consumption varies depending on the model. The maximum current for the NC214 is 13 mA, but the maximum current for the NC234 is 44 mA. With a weight capacity of 170 grams and measurements of 90 millimeters in height, 51 millimeters in width, and 65 millimeters in depth, the compact, space-saving device is ideal for places with a limited amount of floor space. It can operate in a space with an ambient temperature range of 0 to 55 degrees Celsius, and it can be mounted in a CJ-series CPU rack or CJ-series expansion rack. When integrated into the CJ system, the CJ1W-NC214 can handle up to 5 units per rack, and it can support up to 20 units when up to 3 extension racks are added. When configured in this way, the device is placed in the second open slot on the rack. The product complies with all relevant safety and regulatory criteria because it is cULus and EC directive-compliant. Due to its precise control capabilities and flexible mounting choices, the CJ1W-NC214 is a trusted alternative for a range of position control applications within the industrial environment.
