Product image is representative; revision or series may vary. Contact us to request a specific version.
DRT2-OD32ML
The DRT2-OD32ML is a slave connector terminal designed with a MIL connector that includes transistors for efficient signal transmission; it is a reliable and versatile terminal suitable for industrial automation applications. It supports MIL cables, enabling reliable I/O connections. Its 32 output points efficiently handle various output signals. Its rated output current is 0.3 amps/point, 4 amps/common. In addition, the unit is NEMA 4X rated, making it appropriate for usage in harsh places.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for DRT2-OD32ML
| Manufacturer | Omron |
|---|---|
| Product Type | Slave connector terminal |
| Product Line | DRT |
| Part Number | DRT2-OD32ML |
| Weight | 2.00 lbs (0.91 kg) |
| Unit features | MIL Connector Terminals with Transistors |
| MIL cable | Supported |
| I/O connection method | MIL connector |
| Internal I/O common | NPN |
| Output points | 32 points |
| Rated output current | 0.3 A/point, 4 A/common |
| Residual voltage | 1.2 V max. |
| Leakage current | 0.1 mA max. |
| ON delay time | 0.5 ms max. |
| OFF delay time | 1.5 ms max. |
| Communications current consumption | 120 mA max. |
Omron DRT2-OD32ML connection terminal unit has a MIL connection with NPN transistors and is prepared for use in industrial automation systems. The unit connects to relay terminals via a MIL cable, providing a dependable and secure connection for signal transmission. The MIL connector is utilized for I/O connections, ensuring compatibility with MIL connectors often found in industrial applications. The DRT2-OD32ML unit can be mounted as a slave device on a DIN track or screwed to a mounting bracket. This adaptability enables simple integration into control panels or equipment. The unit provides a total of 32 circuits for connecting external devices, with 32 output points and one common. This module has NPN-type I/O; every point has a rated output current of 0.3 amps, but the common terminal can handle maximum 4 amps. It uses 0.3 amps load, and the residual voltage across each output terminal and ground as a maximum value is 1.2 volts. When the outputs are turned off, the device has a low leakage current of 0.1mA (milliamps) at most, indicating negligible current flow. This is critical for preserving energy efficiency and preventing unauthorized activation of connected devices. With an ON-delay time of 0.5 milliseconds (ms) and an OFF-delay time of 1.5 ms, the DRT2-OD32ML unit provides quick response times. It ensures that connected devices are controlled quickly and accurately. It also enables the control of several devices in industrial automation systems simultaneously. The network's current consumption is 24V DC, showing the amount of power required for the item to operate in a networked system. The maximum communications current usage is specified as 120 milliamps. Omron's DRT2-OD32ML connection terminal unit is a versatile component designed for industrial automation systems.
