Schneider Electric 800 Series AS-B838-032

Product image is representative; revision or series may vary. Contact us to request a specific version.

AS-B838-032

|
Need a Specific Revision?

The AS-B838-032 from Schneider Electric is an 800 Series module designed for efficient operation in various applications. This component operates within a specified voltage range and is characterized by a fast response time and multiple output capabilities.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for AS-B838-032

ManufacturerSchneider Electric
Product Line800 Series
Part NumberAS-B838-032
Weight2.00 lbs (0.91 kg)
Space Required1 slot
External Power Supply24 A± 4Vdc, 125 mA
Power Required5 V 160 mA, 4.3 V 1 mA, -5 V 0 mA
Max. Response TimeOFF to ON 1 ms, ON to OFF 1 ms
Operating Voltage20 to 28 VDC
Number of Groups4
Outputs per Group8
Leakage Current1 mA (typical) at 30 VDC
Operating Temperature0 to 60°C
Request a Repair

The AS-B838-032 module, part of Schneider Electric's 800 Series, is engineered for precise performance in control systems. Weighing in at 1.09 kg, this unit requires minimal space, fitting into a single slot. It accepts an external power supply rated at 24 A± 4Vdc with a current of 125 mA. The operational power specifications include a requirement of 5 V at 160 mA, with secondary voltages of 4.3 V at 1 mA and -5 V at 0 mA.

The AS-B838-032 module can switch states rapidly, with a maximum response time of just 1 millisecond for OFF to ON and ON to OFF transitions. It functions effectively within an operating voltage range of 20 to 28 VDC, supporting various applications. The structure contains four groups, each outfitted with eight outputs, allowing for versatile connectivity. Typical leakage current is measured at 1 mA when operating at 30 VDC. Users can expect reliable performance across a wide temperature range of 0 to 60°C, making this module suitable for various environmental conditions.
