Schneider Electric 800 Series AS-P840-000

Product image is representative; revision or series may vary. Contact us to request a specific version.

AS-P840-000

|
Need a Specific Revision?

The AS-P840-000 I/O power supply from Schneider Electric is engineered for precise voltage output in various applications. It operates at input voltages of 115/230 Vac and delivers multiple output voltages, including +5 Vdc, +4.3 Vdc, and -5 Vdc.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for AS-P840-000

ManufacturerSchneider Electric
Product TypeI/O Power Supply
Product Line800 Series
Part NumberAS-P840-000
Weight4.00 lbs (1.81 kg)
Input Voltage115/230 Vac
Output Voltage (+5 Vdc)5.0 A
Output Voltage (+4.3 Vdc)10.0 A
Combined Output Current (55°C)15,000 mA
Combined Output Current (60°C)12,000 mA
Space Requirements (Primary)1.5 slots in H8xx-103 housing
Space Requirements (Secondary)2 slots in H8xx-100 housing
Isolation Voltage (AC)1,500 Vac (60 sec, 47-63 Hz)
Isolation Voltage (DC)2,500 Vdc (60 sec)
Surge ProtectionMeets IEEE-472-1974, ANSI C37-90A-1974
Diagnostic IndicatorACTIVE LED for communication status
Request a Repair

The Schneider Electric AS-P840-000 is an advanced I/O power supply that meets rigorous demands. Its input voltage level can accommodate 115 or 230 Vac, making it versatile for various setups.

The device outputs three distinct voltage levels: +5 Vdc at a current level of 5.0 A, +4.3 Vdc with a capacity of 10.0 A, and -5 Vdc at 0.5 A. Under optimal conditions at 55°C, the combined output current achieves a maximum capacity of 15,000 mA, whereas it is rated at 12,000 mA when operating at 60°C.

Installation requires specific space allocations. In an H8xx-103 housing, it utilizes 1.5 slots for primary applications, while a secondary setup in the H8xx-100 housing demands 2 slots. The power supply's isolation capabilities are noteworthy. It features 1,500 Vac isolation for AC use over a period of 60 seconds and extends to 2,500 Vdc for the same duration in DC applications.

This unit adheres to high standards for surge protection, complying with IEEE-472-1974 and ANSI C37-90A-1974 requirements. Additionally, it comes equipped with an ACTIVE LED diagnostic indicator, enabling users to monitor communication status effectively.
