ATV61H075N4
The ATV61H075N4 from Schneider Electric is a versatile variable speed drive, primarily designed for controlling motor speeds. With a weight of 6.61 lbs, it operates efficiently within a voltage range of 380-480 VAC, accommodating various industrial requirements.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for ATV61H075N4
| Manufacturer | Schneider Electric |
|---|---|
| Product Type | Variable Speed Drive |
| Product Line | Altivar |
| Part Number | ATV61H075N4 |
| UPC | 785901540045 |
| Weight | 11.00 lbs (4.99 kg) |
| Voltage Rating (AC) | 380-480 VAC (-15%/+10%) |
| Input Voltage Frequency | 50-60 Hz (+/-5%) |
| IP Rating | IP20 (upgradable to IP54 with an optional kit) |
| Operating Temperature Range | -10 to 50°C (up to 60°C with derating) |
| Storage Temperature Range | -25 to 70°C |
| Humidity Range | 5-95% RH, (Non-Condensing) |
| Installation Altitude | 1000 meters (up to 3000 meters with derating) |
| Current Rating | 3.7 A at 380V/3.0 A at 480V (input line current) |
| Motor Power Rating | 0.75 kW (1 HP) |
| Communication Protocol | Modbus, CANopen |
| Output Frequency Range | 0.1-599 Hz |
| Switching Frequency | 1-16 kHz adjustable (12 kHz nominal) |
The Schneider Electric ATV61H075N4 functions as a variable speed drive that offers precise control for motor applications. Rated for an AC voltage range of 380 to 480 VAC, this device supports input variations up to -15% to +10%. Its operational capabilities span a frequency input of 50 to 60 Hz, with permissible deviations of +/-5%. Constructed to operate in conditions ranging from -10°C to 50°C, the drive can endure higher temperatures up to 60°C but requires derating.
It is housed in an IP20-rated enclosure but can be upgraded to IP54 when outfitted with an optional kit, thereby enhancing its environmental protection. The device operates effectively in humidity levels as high as 95% RH, provided there is no condensation, and can be used within an installation altitude of up to 1000 meters—a limit that increases to 3000 meters with appropriate de-rating measures.
With a current rating of 3.7 A at 380V and 3.0 A at 480V, the ATV61H075N4 meets the demands of various motor systems, accommodating a power rating of 0.75 kW (1 HP). The adjustable output frequency spans from 0.1 Hz to 599 Hz, allowing for extensive control over motor speed. Additionally, the drive supports a switching frequency adjustable between 1 and 16 kHz, commonly set at 12 kHz to optimize performance. Communication capabilities include Modbus and CANopen protocols, which enhance integration within automation environments.
