Schneider Electric MAGELiS XBTP021010

Product image is representative; revision or series may vary. Contact us to request a specific version.

XBTP021010

|
Need a Specific Revision?

The Schneider Electric XBTP021010 is an Operator Interface Terminal from the MAGELiS series. It features a 2-line by 20-character alphanumeric fluorescent display, designed for ease of readability and functionality in various applications.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for XBTP021010

ManufacturerSchneider Electric
Product LineMAGELiS
Part NumberXBTP021010
Weight1.56 lbs (0.71 kg)
Description of ModuleOperator Interface Terminal
Display TypeAlphanumeric Fluorescent
Display Size2 Lines x 20 Characters
Input Voltage24 V DC
Power Consumption10 W
Communication InterfaceRS-232C
Memory256 KB Flash EEPROM
Function Keys8 or 12 (with LEDs)
Length12.6 cm
Width12.4 cm
Depth2.2 cm
Request a Repair

The XBTP021010, part of Schneider Electric's MAGELiS series, is an interface terminal designed to facilitate interaction with various automated systems. This module utilizes an alphanumeric fluorescent display, providing clear visibility with a configuration of 2 lines by 20 characters, ideal for displaying essential information. Operating at 24 V DC, this device has a power requirement of 10 watts.

For communication, the terminal employs an RS-232C interface, enabling it to connect seamlessly with other devices. Users will appreciate the flexibility of this terminal, which offers either 8 or 12 function keys, including built-in LEDs that indicate status or functionality at a glance. The compact dimensions of the XBTP021010, with a length of 12.6 centimeters, a width of 12.4 centimeters, and a depth of 2.2 centimeters, contribute to its usability in space-restricted applications.

With a weight of 0.4 kilograms (or 0.88 pounds), it remains lightweight for easy installation and handling. Additionally, the terminal is equipped with 256 KB of Flash EEPROM memory, providing adequate space for storing essential operational data.
