Schneider Electric Modicon 800 AS-J890-001

Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with DO Supply's 2-year warranty.

Learn more

AS-J890-001

Need a Specific Revision?

The AS-J890-001 part from Schneider Electric operates as an RIO interface module, facilitating extensive functionalities of communication. It is designed to accommodate multiple RIO topologies and supports up to 1024 input and output bits per drop.

Ships Today, May 22.

Order within 5 hrs 21 mins.

2 Year DO Supply Warranty

In Stock

Ships from Raleigh, NC

Learn more

Warranty

We sell industrial automation parts backed by our 2-year DO Supply Warranty.
Shipping

Same-day domestic and expedited international shipping with UPS, FedEx, DHL, and more.
Payment Methods

AMEX, Visa, MasterCard, Discover, wire transfer, and more, plus flexible payment plans.
Repairs & Exchanges

Repair and exchange services for all existing automation products.
Reseller Options

Drop shipping, blind shipping, and account shipping with no extra fees.

Technical specifications for AS-J890-001

Manufacturer	Schneider Electric
Series	Modicon 800
Part Number	AS-J890-001
Product Type	RIO Interface Module
RIO Cable Ports	1 or 2 F connector ports (model dependent)
Supported RIO Topologies	Linear and dual redundant
Communication Speed	1.544 Mbits/s
Comm Link Time	< 1 ms for 256 I/O points
Drop Hold-Up Time	Programmable, 0.3 s to 100 s (100 ms increments)
Power Consumption	1.85 A at +5 V
LED Indicators	Status for RIO interface and diagnostics
DIP Switch Configuration	For RIO drop address settings
Module Slot Size	1.5 slots in I/O housing
I/O Capacity per Drop	Up to 1024 input and 1024 output bits
Supported Controller Types	Compatible with 984 Programmable Controllers

Request a Repair

Operating as a pivotal component in Schneider Electric's Modicon 800 series, the AS-J890-001 RIO interface module enables robust communication within various I/O applications. It supports one or two F connector ports, depending on its specific model. This module is adaptable to both linear and dual redundant RIO topologies, ensuring versatility in its applications.

The communication speed achieved by this module is 1.544 Mbits/s. Comm link durations are notably fast, taking less than 1 ms for 256 input/output points. Additionally, the drop hold-up time can be programmed between 0.3 seconds and 100 seconds, in 100 ms increments, to provide flexibility based on operational requirements.

For power needs, the AS-J890-001 module consumes 1.85 A at a +5 V supply. Users can monitor the status through LED indicators that provide feedback on RIO interface health and diagnostics. Configuration is straightforward, facilitated by DIP switches for setting RIO drop addresses.

The AS-J890-001 module occupies 1.5 slots within the I/O housing, accommodating a significant I/O capacity of up to 1024 inputs and 1024 outputs per drop. It is also compatible with 984 Programmable Controllers, making it an effective choice for comprehensive control systems.
