170ADM35010
The 170ADM35010 from Schneider Electric forms part of the Modicon Momentum series. This discrete I/O base features 16 inputs and 16 outputs, arranged in two groups of eight outputs and one group of 16 inputs, making it versatile for various applications.
-
We sell industrial automation parts backed by our 2-year DO Supply Warranty.
-
Same-day domestic and expedited international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, and more, plus flexible payment plans.
-
Repair and exchange services for all existing automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for 170ADM35010
| Manufacturer | Schneider Electric |
|---|---|
| Series | Modicon Momentum |
| Part Number | 170ADM35010 |
| Product | Discrete I/O Base |
| Number of Channels | 16 Inputs, 16 Outputs |
| Groups | 2 Groups with 8 Outputs and 1 Group with 16 Inputs |
| Discrete Input Voltage | 24 V DC |
| Discrete Output Voltage | 24 V DC, Up To 30V DC |
| Output Logic | Positive |
| Input Logic | Positive |
| Solid-State Switch Outputs | Supported |
| Protective Treatment | TC Treatment |
| Maximum Relative Humidity | 95% Without Condensation |
| Peak Output Current | 5 Amps |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | -40°C to 85°C |
Schneider Electric's 170ADM35010 unit is designed as a discrete I/O base with robust functionality. It consists of a total of 16 discrete input channels and 16 discrete output channels, organized into two groups housing eight outputs each, alongside a separate group featuring 16 inputs. This architecture makes it well-suited for varied configurations within industrial applications.
The unit operates at a discrete input voltage of 24 V DC and can output the same voltage, accommodating levels up to 30 V DC. It follows a positive logic scheme for both its inputs and outputs while being compatible with solid-state switch outputs, thus ensuring efficient operation.
To enhance durability, the 170ADM35010 features TC protective treatment, which is crucial in maintaining performance under challenging environments. It can handle a maximum relative humidity of 95%, provided there is no condensation present.
This device can support a peak output current of up to 5 Amps, making it capable of managing substantial loads. In terms of temperature adaptability, it functions effectively within an operational range from 0°C to 60°C and can endure storage conditions between -40°C to 85°C, adding flexibility for various settings and applications.
