170ENT11001
The 170ENT11001 is a communication adapter from Schneider Electric’s Modicon Momentum series. It facilitates high-speed data transmission with baud rates of either 10 or 100 megabits per second and supports Ethernet protocols for robust networking.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for 170ENT11001
| Manufacturer | Schneider Electric |
|---|---|
| Product Type | Communication Adapter |
| Product Line | Modicon Momentum |
| Part Number | 170ENT11001 |
| EAN | 3595862034302 |
| Weight | 1.00 lbs (0.45 kg) |
| Baud Rate | 10 or 100 megabits per second |
| Communication Protocol | Ethernet Transmission Control Protocol/Internet Protocol |
| Ambient Operating Temperature | 0 to 60°C (in a non-condensing environment) |
| Protection Class | IP20 |
| Access Method | Master/Slave and peer-to-peer (P2P) |
| Transmission Cable Type | Shielded twisted pairs cable |
| Ethernet Port Type | 100BASE-TX |
| Electrical Connection Type | RJ45 connector for 100BASE-TX |
| Number of Devices Per Segment | 0 to 32 per segment |
| Network Topology | Star network and multi-drop |
| Status Indicators | 4 LED indicators (3 green and 1 yellow LEDs) |
| Storage Temperature | -40 to 85°C (in a non-condensing environment) |
| Type of Control Parameter | CRC-32 |
| Maximum Cable Distance Between Devices | 3,280 feet (1,000 meters) |
The Modicon Momentum 170ENT11001 by Schneider Electric serves as an efficient communication adapter designed for various networking needs. This device operates using Ethernet Transmission Control Protocol/Internet Protocol and supports dual baud rates of 10 and 100 megabits per second, ensuring flexible speed options for data communication. The recommended transmission medium involves shielded twisted pair cables, allowing reliable connections.
Housed with an RJ45 connector, it is compatible with the 100BASE-TX Ethernet port type for seamless integration. The operational range for this adapter spans from 0 to 60°C, ideal for regular industrial conditions, while the storage temperature extends from -40 to 85°C, ensuring durability in extreme environments.
This adapter adopts a master/slave and peer-to-peer (P2P) access method, facilitating efficient communication protocols across devices. The device supports a maximum cable length of 3,280 feet (1,000 meters) between networked devices, allowing significant flexibility in placement. Configuration can accommodate up to 32 devices per segment.
Additionally, it is equipped with status indicators featuring 3 green and 1 yellow LED lights to denote operational status clearly. Its IP20 class of protection ensures it meets basic standard requirements, and it employs CRC-32 as the control parameter for ensuring data integrity.
