Schneider Electric Modicon Momentum 171CCC96020

Product image is representative; revision or series may vary. Contact us to request a specific version.

171CCC96020

|
Need a Specific Revision?

The 171CCC96020 from Schneider Electric is a processor adapter module designed for the Modicon Momentum series. It supports Ethernet communication and features a dual-port architecture, allowing for integrated I/O operations.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for 171CCC96020

ManufacturerSchneider Electric
Product TypeM1/M1E Processor Adapter Module
Product LineModicon Momentum
Part Number171CCC96020
EAN3595860019318
Weight1.00 lbs (0.45 kg)
Number of Communication PortsOne Ethernet port and one Input/Output bus port
Ambient Operating Temperature0 to 60°C (in a non-condensing environment)
Communication ProtocolEthernet
Clock Frequency50 megahertz
Storage Temperature-40 to 85°C (in a non-condensing environment)
Flash Memory Capacity512 kilobytes
Word Length16 bit
Memory TypeFlash memory and Random Access Memory (RAM)
RAM Capacity544 kilobytes
Input/Output Limit Processor Capacity8,192 bits (maximum)
Scan Time0.3 milliseconds per kilobytes
Discrete Input/Output Processor Capacity8,192 bits (maximum)
Register Input/Output Processor Capacity26,048 words (maximum)
Request a Repair

The Schneider Electric 171CCC96020 serves as an M1/M1E processor adapter module within the Modicon Momentum series, facilitating communication and processing tasks in industrial settings. This module incorporates one Ethernet port alongside an input/output bus port, allowing for versatile connectivity. It operates on a clock frequency of 50 megahertz, ensuring rapid data handling capabilities.

In terms of memory, it provides a flash memory capacity of 512 kilobytes as well as a RAM capacity of 544 kilobytes, which can be utilized for storing essential data and instructions.

Designed to perform in ambient temperatures ranging from 0 to 60°C, the unit remains effective in challenging environments, provided they are non-condensing. Additionally, it is capable of withstanding storage conditions between -40 and 85°C. The processor's capacity allows for handling input/output limits, with a maximum of 8,192 bits and a register input/output capacity of 26,048 words.

With a scan rate of 0.3 milliseconds per kilobyte, the efficiency of this module is reinforced. The seamless integration of flash memory and RAM contributes to its reliability and robust performance in automated control applications.
