Schneider Electric Modicon Quantum 140CPS12400

Product image is representative; revision or series may vary. Contact us to request a specific version.

140CPS12400

|
Need a Specific Revision?

The 140CPS12400 is a redundant power supply module designed for use in Schneider Electric's Modicon Quantum series. This module supports dual input voltage levels of 115/230 V AC and features a weight of 1.43 lbs for straightforward installation.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for 140CPS12400

ManufacturerSchneider Electric
Product TypePower Supply Module
Product LineModicon Quantum
Part Number140CPS12400
EAN3595861126657
Weight2.00 lbs (0.91 kg)
GTIN3595861126657
Power Supply TypeRedundant
Input Voltage115/230 V AC
Input Current1100 mA at 115 V and 600 mA at 230 V
Inrush Current19 A at 230 V, 38 A at 115 V
Rated Power130 VA
Associated Fuse Rating2 A, slow-blow
Output Voltage5.1 V DC
Local Signalling1 green "PWR OK" LED
Operating Altitude5000 m
Relative Humidity95% without condensation
Ambient Operating Temperature0…60 °C
Ambient Storage Temperature-40…85 °C
Request a Repair

The Schneider Electric 140CPS12400 power supply module is engineered for redundancy in operation, ensuring continuous performance in Schneider's Modicon Quantum series. This power supply operates with input voltages of either 115 or 230 V AC, drawing a maximum current of 1100 mA at 115 V and 600 mA at 230 V. It accommodates inrush currents of 38 A at 115 V and 19 A at 230 V, demonstrating robust performance during startup.

Weighing 1.43 lbs, this compact module is ideal for various installations. It has a rated power output of 130 VA and an associated fuse rating of 2 A, which is slow-blow to mitigate unexpected surges. The output voltage is maintained at a stable 5.1 V DC, suitable for numerous devices.

For local status indication, it includes one green "PWR OK" LED, allowing easy monitoring of operational status. This module can operate in ambient conditions within the range of 0 to 60 °C, and it can withstand altitudes up to 5000 meters, making it versatile for different applications. With a relative humidity tolerance of up to 95% without condensation, the 140CPS12400 is well-suited for challenging environments. Furthermore, it can be safely stored at temperatures ranging from -40 to 85 °C, ensuring longevity under adverse conditions.
