140CPS12420

Schneider Electric's 140CPS12420 is an essential power supply module tailored for the Modicon Quantum series and is equipped with redundancy features. This module can process input voltages of either 115 or 230 VAC, with an effective operating power rating of 130 VA. It accepts an input frequency range of 50/60 Hz, ensuring compatibility with a wide variety of power systems.

In terms of safety, the 140CPS12420 is safeguarded by a 2 A slow-blow fuse, which helps protect against transient overloads. It provides an output voltage of 5.1 VDC, suitable for powering control systems and devices. Depending on the input voltage, this power supply can deliver output currents of 1100 mA when operating at 115 VAC or 600 mA at 230 VAC.

Additionally, this module is outfitted with one normally closed (NC) alarm output, facilitating effective monitoring of power supply status. The status indication functionality allows users to easily ascertain operational readiness. With a weight of 0.58 kg, this module is relatively lightweight and can be comfortably installed in various control environments.

Regarding environmental conditions, the device operates efficiently within a temperature range of 0°C to 60°C, making it suitable for diverse applications that may experience varying temperature conditions.
