140DDO36400
The Modicon Quantum 140DDO36400, produced by Schneider Electric, is a device designed for managing discrete outputs efficiently. This unit is capable of handling up to 96 output channels, with an operational voltage rating of 24V DC and output limits ranging from 19.2 to 30V DC.
-
We sell industrial automation parts backed by our 2-year DO Supply Warranty.
-
Same-day domestic and expedited international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, and more, plus flexible payment plans.
-
Repair and exchange services for all existing automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for 140DDO36400
| Manufacturer | Schneider Electric |
|---|---|
| Series | Modicon Quantum |
| Part Number | 140DDO36400 |
| Output Type | Discrete Outputs |
| Number of Channels | 96 Channels |
| Discrete Output Voltage | 24V DC |
| Output Voltage Limits | 19.2 to 30V DC |
| Output Logic | Negative (Sink) |
| Addressing Requirement | 6 Output Words |
| Groups of Channels | 6 Groups of 16 |
| Maximum Leakage Current | 1 mA at 24V |
| Surge Current | 2 Amps |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | -40°C to 85°C |
| Mounting Type | Rack Mountable |
| Maximum Relative Humidity | 95% Without Condensation |
| CE Marking | Yes |
| Power Dissipation | 7W |
Schneider Electric's 140DDO36400 part of the Modicon Quantum series functions as a discrete output module designed for industrial applications. This device supports a total of 96 discreet output channels with a nominal output voltage of 24V DC. The operational voltage limits extend from 19.2V to 30V DC, allowing for a degree of flexibility in varying operational environments.
The output configuration operates on a negative (sink) logic structure and necessitates 6 output words for proper addressing, facilitating organized communication with control systems. Channels are grouped effectively, consisting of 6 sets with 16 channels per group, assisting in streamlined wiring and connection management.
Performance is safeguarded with a maximum leakage current of 1 mA at 24V, handling transient conditions with a surge current capability of 2 Amps. Designed for diverse industrial applications, it remains operational in an ambient temperature range of 0°C to 60°C, withstanding storage conditions between -40°C and 85°C.
Its mounting design is rack-mountable, simplifying installation in panel setups. Additionally, this module can tolerate up to 95% relative humidity without condensation. Compliance with CE marking ensures it meets international regulatory standards, enhancing safety in deployment. This unit also has a power dissipation rating of 7W, confirming its efficiency in power usage.
