BMXDDI3202K

Schneider Electric's BMXDDI3202K discrete input module facilitates efficient input handling in automation systems. This module is equipped with 32 isolated inputs, handling input voltages at a steady 24 volts DC for reliable performance. It supports a sensor supply voltage spanning 19 to 30 volts DC, allowing compatibility with multiple sensors. The module’s compact design weighs just 0.25 pounds (0.11 kilograms).

In terms of electrical specifications, the input current rating is measured at 2.5 milliamperes, and the input impedance stands at a substantial 9,600 ohms. Power dissipation is maintained at 3.9 watts, ensuring that the module operates optimally. For easier monitoring, LED indicators are incorporated to display the status of each input.

The BMXDDI3202K also comes equipped with notable protection features, including reverse polarity protection set at 0.5 amperes, along with one external fuse for each channel group. Operating in non-condensing environments, the module can function effectively within an ambient temperature range of 0 to 60°C. For storage, this module can withstand temperatures between -40 to 85°C, demonstrating its ruggedness for various environmental conditions. Additionally, the DC filtering time is typically 4 milliseconds, with a maximum of 7 milliseconds, ensuring swift input processing for efficient control.
