Schneider Electric Modicon 140CRA93101

Product image is representative; revision or series may vary. Contact us to request a specific version.

140CRA93101

|
Need a Specific Revision?

The Schneider Electric Modicon 140CRA93101 is a dedicated adaptor module for RIO drop applications. Designed for easy connectivity, it features a female F type connector in an elbow design and supports a transmission rate of 1544 Mbit/s.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for 140CRA93101

ManufacturerSchneider Electric
Product LineModicon
Part Number140CRA93101
EAN3595861133792
Weight1.00 lbs (0.45 kg)
ProductAdaptor Module
DescriptionRIO drop adaptor module
Electrical Connection1 female connector F type with elbowed shape
SAT Connector1 female F type
Number of Channels1
Maximum Number of I/O Expansion Module27
Type of Cable75 Ohm coaxial
Transmission Rate1544 Mbit/s
Dynamic Range35 dB
Isolation Voltage500 V DC coaxial center and ground
Power Dissipation3W, 1 channel
Request a Repair

The 140CRA93101 adaptor module from Schneider Electric's Modicon series is a specialized component designed for RIO drop systems. It features a unique elbowed female F type connector, simplifying installation in tight spaces while ensuring secure electrical connections. This module supports a single channel and can link to a maximum of 27 I/O expansion modules, enhancing the flexibility of system architecture.

The module operates with a 75 Ohm coaxial cable, which is essential for sustaining a high transmission rate of 1544 Mbit/s. It boasts a dynamic range of 35 dB, allowing for efficient communication over coaxial connections. In terms of electrical safety, it provides a sturdy isolation voltage of 500 V DC between the coaxial center and ground, safeguarding against potential voltage spikes. The power dissipation of 3 watts ensures that a single channel can operate efficiently without overheating.
