Schneider Electric Modicon AS-BDEP-220

Product image is representative; revision or series may vary. Contact us to request a specific version.

AS-BDEP-220

|
Need a Specific Revision?

The AS-BDEP-220 is a digital input module from Schneider Electric's Modicon series. It supports up to 16 digital input points with an operating voltage of 24 VDC, functioning reliably across various environmental conditions.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for AS-BDEP-220

ManufacturerSchneider Electric
Product LineModicon
Part NumberAS-BDEP-220
Weight0.75 lbs (0.34 kg)
Product NameInput Module
Input TypeDigital
Number of DI Points16
Operating Voltage24 VDC
Altitude2000 m
EnvironmentNo Corrosive Gases
Relative Humidity95% or less (non-condensing)
Minimum Ambient Operating Temperature0°C
Maximum Ambient Operating Temperature55°C
Minimum Ambient Storage Temperature-20°C
Maximum Ambient Storage Temperature60°C
Request a Repair

The AS-BDEP-220 input module from Schneider Electric's Modicon range is a compact solution designed for digital applications. This module features a total of 16 digital input points. With an operational voltage of 24 VDC, it is adept at handling various control signals effectively. Weighing only 0.12 kg (or 0.264 lbs.), it offers a lightweight option suitable for numerous configurations. For altitude considerations, this module can perform effectively at elevations as high as 2000 meters.

Engineered with strict environmental controls in mind, the AS-BDEP-220 is nonsensitive to corrosive gases, ensuring its reliability in diverse settings. In terms of humidity tolerance, it functions optimally at a relative humidity level of 95% or lower, without the issues associated with condensation. The ambient operating temperature range runs from a minimum of 0°C to a maximum of 55°C, providing flexibility in various climate conditions. Additionally, it can be safely stored in temperatures between -20°C and 60°C, making it versatile for both operational and storage environments.
