Product image is representative; revision or series may vary. Contact us to request a specific version.
TSXREY200
The TSXREY200 from Schneider Electric is a Bus X Remote Module with efficient dual-channel capabilities. This module operates in a master/slave configuration and requires a single SUB-D 9 connector for electrical connections.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for TSXREY200
| Manufacturer | Schneider Electric |
|---|---|
| Product Line | TSX COMPACT |
| Part Number | TSXREY200 |
| EAN | 3595860019097 |
| Weight | 0.31 lbs (0.14 kg) |
| Product | Bus X Remote Module |
| Number of Channels | 2 |
| Method of Access | Master/Slave |
| Electrical Connection | 1 Connector SUB-D 9 |
| Current Consumption | 500 mA at 5 V DC |
| Local Signalling | LED |
| Module Format | Standard |
| Certification | CE |
| Maximum Ambient Temperature | 60 degrees Celsius |
| Minimum Ambient Temperature | 0 degrees Celsius |
| Operating Humidity | Up to 80% (non-condensing) |
| Storage Humidity | Up to 80% (non-condensing) |
| Maximum Operating Altitude | 1000 meters above sea level without derating |
The TSXREY200 model serves as a Bus X Remote Module designed by Schneider Electric. It features two separate channels, allowing flexibility for various applications. With a master/slave access method, this module ensures efficient communication within the system. A SUB-D 9 connector provides a straightforward electrical interface for installations.
This remote module exhibits a current consumption of 500 mA while operating on a 5 V DC supply. Local signaling is achieved through integrated LED indicators, providing instant feedback on the module's status. Built in a standard format, the TSXREY200 is CE certified, indicating compliance with essential electrical safety regulations.
Furthermore, this unit is capable of functioning in diverse environmental conditions. It can operate effectively in temperature extremes ranging from 0 degrees Celsius up to 60 degrees Celsius. Humidity levels are accommodated, supporting up to 80% relative humidity without condensation for both operable and storage states. The module also performs well at altitudes of up to 1000 meters above sea level without experiencing derating issues, ensuring reliable functionality in higher elevations.
