TSXAMZ600

Schneider Electric's TSXAMZ600 analog I/O module provides an efficient solution for interfacing with analog inputs and outputs in control systems. It comprises four input channels and two output channels, allowing for versatile application in monitoring and control tasks. The module reads analog inputs ranging from 4 to 20 mA, translating these signals effectively due to its 11-bit analog-to-digital conversion capabilities. The measurement resolution spans from 0 to 20 mA, ensuring accurate readings for various applications.

For signal acquisition, this module operates with a period of 16 milliseconds, while its response time is recorded at 400 microseconds, providing timely information processing. With a current consumption of 180 mA, the module is designed to perform efficiently in a variety of settings. Isolation voltage rated at 1000 V AC enhances safety by preventing unwanted electrical interference or surges.

The unit weighs 0.24 kg and has an input impedance of 250 ohms, making it lightweight and easy to integrate. Its operational reliability extends to environments with humidity levels up to 80% relative humidity, non-condensing. Additionally, it can be stored under similar humidity conditions. This module is rated for maximum operating altitudes up to 1000 meters above sea level without any reduction in performance. The TSXAMZ600 module is ideal for implementing in systems requiring precise analog input and output functionalities.
