Product image is representative; revision or series may vary. Contact us to request a specific version.
TSXH5724M
The TSXH5724M from Schneider Electric represents a highly capable micro PLC from the TSX Micro PLCs series. Designed for various automation tasks, it supports significant I/O capacities and multiple integrated connection options.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for TSXH5724M
| Manufacturer | Schneider Electric |
|---|---|
| Product Line | TSX Micro PLCs |
| Part Number | TSXH5724M |
| EAN | 3595863921243 |
| Weight | 1.00 lbs (0.45 kg) |
| Number of Racks | 1 (6/8/12 slots) |
| Discrete I/O Processor Capacity | 1024 I/O |
| Analog I/O Processor Capacity | 80 I/O |
| Number of Application-Specific Channels | ≤ 24 |
| Number of Process Control Channels | ≤ 10 (up to 30 simple loops) |
| Integrated Connection Types | Ethernet TCP/IP RJ45, USB port (USB type A 12 Mbit/s), Serial link (female mini DIN RS485 19.2 kbit/s) |
| Memory Description | PCMCIA card (16384 kB additional data storage), Internal RAM (with PCMCIA card: 768 kB program, 192 kB data; without PCMCIA card: 192 kB program and data) |
| Execution Time per Instruction | 0.039-0.057 µs Boolean (without PCMCIA card), 0.048-0.057 µs Boolean (with PCMCIA card), 0.054-0.073 µs word or fixed-point arithmetic (with PCMCIA card), 0.054-0.073 µs word or fixed-point arithmetic (without PCMCIA card), 0.055-0.063 µs floating points (with PCMCIA card), 0.055-0.063 µs floating points (without PCMCIA card) |
| Number of Instructions per ms | 11.4 Kinst/ms (65% Boolean + 35% fixed arithmetic without PCMCIA card), 11.4 Kinst/ms (65% Boolean + 35% fixed arithmetic with PCMCIA card), 15.75 Kinst/ms (100% Boolean without PCMCIA card), 15.75 Kinst/ms (100% Boolean with PCMCIA card) |
| System Overhead | 1 ms master task |
| Marking | CE |
| Port Ethernet | 10BASE-T/100BASE-TX |
| Max. Size of Object Areas | 192 kB data exchanged via CPU Sync link |
| Protective Treatment | TC |
The Schneider Electric TSXH5724M is a powerful micro PLC that meets diverse industrial automation needs. This compact controller supports a single rack configuration that holds between 6 and 12 slots, accommodating varied setup requirements. With a discrete I/O processing limit of 1024 I/O and an additional capacity for 80 analog I/O points, the TSXH5724M facilitates substantial input and output capabilities.
Regarding functional versatility, the unit houses up to 24 application-specific channels and provides up to 10 process control channels to manage as many as 30 straightforward loops. Communication is streamlined via integrated connection types, including Ethernet TCP/IP (RJ45), a USB port for fast data exchange, and a serial link (female mini-DIN RS485) supporting 19.2 kbit/s.
Memory management is further enhanced with a PCMCIA card that allows for an additional 16384 kB of data storage. When a PCMCIA card is installed, internal RAM runs at 768 kB for programs and 192 kB for data. Without a PCMCIA card, the RAM limits include 192 kB split equally between programs and data.
Performance-wise, the execution times for various instruction types range from 0.039 µs to 0.073 µs, depending on whether a PCMCIA card is present. The controller can handle 11.4 Kinst/ms for combined Boolean and fixed arithmetic operations or 15.75 Kinst/ms for pure Boolean operations. The system overhead is maintained at a master task duration of 1 millisecond.
CE certification markings indicate compliance with applicable standards, and the controller supports Ethernet connection options at 10BASE-T/100BASE-TX speeds. For object area exchanges, a maximum size of 192 kB is specified via the CPU Sync link, while the device has a protective treatment classified as TC.
