1FT6034-1AK71-3AH1

The Siemens motor designated 1FT6034-1AK71-3AH1 serves as a part of the 1FT6 series, featuring characteristics ideal for demanding applications. This servo motor is capable of precisely controlling movement with a rated speed of 6,000 revolutions per minute (RPM) and can achieve a top speed of 9,700 RPM. It is designed to accommodate a single pole setup, providing efficient motor control.

A notable feature of this model is its holding brake, which maintains position during stationary periods. The torque specification stands at 2 Newton-meters, allowing for substantial load handling. Cooling for the motor is accomplished through natural methods ensuring effective thermal management without the need for additional cooling equipment.

Operating using a 3-phase input, the current rating for this motor is 2.6 Amperes, confirming its compatibility with standard industrial power supplies. The motor type is classified as a permanent-magnet synchronous motor, which is beneficial for high efficiency and precise positioning.

Connectivity is facilitated through a signal connection bracket and a power connection connector, both located at the axial non-drive end (NDE) of the unit. For position feedback, the motor integrates an incremental encoder that provides a resolution of 2,048 pulses per revolution, essential for high-accuracy applications. The overall protection rating for the motor is IP65, ensuring it remains operational in challenging environments.
