BQD335
The BQD335 from Siemens is a three-pole circuit breaker designed for panelboard installation. It operates up to 35 Amps with a voltage rating of 480 VAC, offering durable thermal magnetic protection with a molded case design.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for BQD335
| Manufacturer | Siemens |
|---|---|
| Product Type | Circuit Breaker |
| Product Line | BQD Series |
| Part Number | BQD335 |
| UPC | 783643277380 |
| Poles | 3 Poles |
| Current Rating | 35 Amps |
| Mounting | Panelboard |
| Connection | Low Tab |
| Voltage Rating | 480 VAC |
| Interrupting Rating | 14 kAIC |
| Enclosure | Molded Case |
| Protection | Thermal Magnetic |
| Certification | UL, CSA |
| Operating Temperature | 32 to 104 degrees Fahrenheit |
Siemens' BQD335 is a robust circuit breaker specifically designed for panelboard mounting. This device features three poles and is capable of handling a maximum current of 35 Amps. Its input voltage rating reaches up to 480 VAC, making it appropriate for substantial electrical systems.
Protected by a molded case, the BQD335 employs thermal magnetic protection to effectively respond to overloads and short circuits. It is rated for an interrupting capacity of 14 kAIC, ensuring safety during fault conditions. Connection options include low tab methods for easy installation.
This circuit breaker meets stringent safety standards, holding UL and CSA certifications. It is built to perform within an operating temperature range of 32 to 104 degrees Fahrenheit, accommodating various environmental conditions. The unique combination of capabilities and certifications makes the BQD335 a reliable choice for circuit protection in industrial settings.
