BQD370
The BQD370 is a molded case circuit breaker from Siemens' BQD Series. It is rated for a continuous current of 70 A with a voltage capacity of 277/480 VAC, suitable for 3-phase applications.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for BQD370
| Manufacturer | Siemens |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | BQD Series |
| Part Number | BQD370 |
| UPC | 783643277434 |
| Rated Current | 70 A |
| Color Type | Black |
| Connection Type | Low Tab Connection |
| Min. Frequency | 50 Hz |
| Max. Frequency | 60 Hz |
| Interrupt Rating at 480 VAC | 14 kA |
| Number of Poles | 3 Poles |
| Phase Type | 3-Phase |
| Rated Voltage | 277/480 VAC |
| Wire Size | 8 to 1 AWG, 6 to 1/0 AWG |
The Siemens BQD370 circuit breaker offers reliable protection in demanding electrical systems. As a molded case type, it effectively manages a rated current of 70 A and supports both 277 and 480 VAC operating voltages. With three poles, this breaker is configured for use in 3-phase environments, making it suitable for industrial applications. The BQD370 is designed to handle frequencies between 50 and 60 Hz, ensuring compatibility with a variety of power systems.
Its interrupt rating is robust at 14 kA for applications at 480 VAC, providing a layer of safety during fault conditions. Installation is made straightforward with its low tab connection, allowing for secure connections with minimal effort.
When it comes to wiring, the BQD370 accommodates a range from 8 to 1 AWG for copper wiring and 6 to 1/0 AWG for aluminum, making it versatile for different installation setups. Packaged in a sleek black housing, this circuit breaker combines functionality with consideration for workplace aesthetics. The UPC for this product is 783643277434, facilitating easy identification and procurement.
