6SE6400-1PB00-0AA0

|

Need a Specific Revision?

The 6SE6400-1PB00-0AA0 is a PROFIBUS DP module from Siemens within the MICROMASTER series. It is designed to enable communication for MICROMASTER 4 drives and supports a data transfer rate reaching up to 12 Mbaud.

Ships Tomorrow, May 13.

2 Year DO Supply Warranty

In Stock

Ships from Raleigh, NC

Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with DO Supply's 2-year warranty.

Learn more

Warranty

We sell industrial automation parts backed by our 2-year DO Supply Warranty.
Shipping

Same-day domestic and expedited international shipping with UPS, FedEx, DHL, and more.
Payment Methods

AMEX, Visa, MasterCard, Discover, wire transfer, and more, plus flexible payment plans.
Repairs & Exchanges

Repair and exchange services for all existing automation products.
Reseller Options

Drop shipping, blind shipping, and account shipping with no extra fees.

Technical specifications for 6SE6400-1PB00-0AA0

Manufacturer	Siemens
Series	MICROMASTER
Part Number	6SE6400-1PB00-0AA0
Product Type	PROFIBUS DP module
Supported Drive Series	Compatible with MICROMASTER 4 (MM4 FX/GX)
Protocol	PROFIBUS DP communication
Max Data Rate	Up to 12 Mbaud
Interface Port	RS-485 PROFIBUS DP port
Connector Type	9-pin Sub-D connector
Power Supply	24 V DC input from external source
Compatibility Requirement	Needs 6GK1500-0EA02 connector for proper installation
Mounting	Fits MICROMASTER enclosures
Cooling	Natural air cooling
Operating Temperature	-10 to 50 degrees Celsius
Storage Temperature	-25 to 70 degrees Celsius
Output Voltage	5V from electrically isolated supply
Approximate Dimensions	161 x 73 x 43.5 mm

Request a Repair

Siemens' 6SE6400-1PB00-0AA0 is categorized as a PROFIBUS DP module that facilitates robust communication between devices in the MICROMASTER series. Specifically, it is designed to work with the MICROMASTER 4 series, including both MM4 FX and GX variants. This module will operate effectively using the PROFIBUS DP communication protocol, which is known for its reliability in industrial networks.

The 6SE6400-1PB00-0AA0 is equipped with an RS-485 PROFIBUS DP port and a maximum data transfer rate of up to 12 Mbaud. It utilizes a 9-pin Sub-D connector for a secure interface. This module's power supply requirements stipulate a 24 V DC input from an external source, ensuring it operates correctly. For installation, the 6GK1500-0EA02 connector is crucial to ensure compatibility and secure connections.

The module's design allows for mounting within MICROMASTER enclosures, offering flexibility during integration into existing systems. Cooling is achieved through natural air circulation, minimizing the necessity for additional cooling components. The unit can function within an operating temperature range of -10 to 50 degrees Celsius. It can be stored at temperatures from -25 to 70 degrees Celsius when not in use, highlighting its versatility in varied environments.

Additionally, the module outputs a 5V supply from an electrically isolated source. Its dimensions are approximately 161 x 73 x 43.5 mm, making it compact enough for efficient use in confined spaces.
