Siemens MICROMASTER 6SE6400-4BD11-0AA0

Product image is representative; revision or series may vary. Contact us to request a specific version.

6SE6400-4BD11-0AA0

|
Need a Specific Revision?

Part number 6SE6400-4BD11-0AA0 is a braking resistor from Siemens, belonging to the MICROMASTER series. Designed for use in a voltage class of 400V, this unit is effectively suited for input voltages ranging from 380 to 480V AC, accommodating both 50Hz and 60Hz frequency requirements.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for 6SE6400-4BD11-0AA0

ManufacturerSiemens
Product LineMICROMASTER
Part Number6SE6400-4BD11-0AA0
UPC783087640733
Weight2.00 lbs (0.91 kg)
DescriptionBraking Resistor
Voltage Class (input)400V
Input Voltage Range380-480 V AC at 50/60 Hz
Resistance390 Ω
Peak Power Rating2000 W
Continuous Power Rating100 W
Enclosure RatingIP20
Temperature Range0°C to 40°C
Storage Temperature Range-20°C to 60°C
Humidity Range5% to 95% non-condensing
ComplianceCE marked, compliant with RoHS Directive
Request a Repair

Siemens offers the 6SE6400-4BD11-0AA0 braking resistor as an essential component in the MICROMASTER series. It supports an input voltage class of 400V, operating efficiently within an input voltage range of 380-480V AC at both 50Hz and 60Hz. The resistor features a resistance value of 390 Ω, making it effective in applications that require load damping.

The unit has a peak power rating of 2000 watts, enabling it to effectively manage brief surges in power, while its continuous power rating remains at 100 watts during regular operation. Constructed with dimensions of 230 mm in height, 72 mm in width, and 43.5 mm in depth, this device fits conveniently in limited spaces. The IP20 enclosure rating provides adequate safeguarding against solid foreign objects, although it should not be exposed to moisture.

Approximately 1 kg in weight, this braking resistor operates within a temperature scope of 0°C to 40°C and can endure storage conditions from -20°C to 60°C. It tolerates humidity levels from 5% to 95% without condensation, ensuring versatility across various environments. Additionally, the equipment is marked with CE marking and complies with the RoHS Directive standards, demonstrating its adherence to European regulations.
