Siemens MICROMASTER 6SE6440-2UD15-5AA1

Product image is representative; revision or series may vary. Contact us to request a specific version.

6SE6440-2UD15-5AA1

|
Need a Specific Revision?

The Siemens 6SE6440-2UD15-5AA1 AC drive is engineered for efficient operation in a variety of applications. It is an adaptable device designed to function with an input voltage ranging from 380 to 480 volts AC.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for 6SE6440-2UD15-5AA1

ManufacturerSiemens
Product LineMICROMASTER
Part Number6SE6440-2UD15-5AA1
UPC783087635678
Weight1.31 lbs (0.60 kg)
ProductAC Drive
Input Voltage Type3-Phase AC
Input Voltage Range380-480V AC
Input Frequency47-63 Hz
Input Current2.8 A
Output Voltage Type3-Phase AC
Output Voltage Range0 to input voltage
Output Frequency0 to 650 Hz
Output Current1.6 A
Motor Power0.55 kW
IP RatingIP20
Operating Temperature-10 to 55 degrees Celsius
Maximum Operating Humidity80% RH without condensation
Maximum Storage Humidity80% RH without condensation
Maximum Operating Altitude1000 meters above sea level
Request a Repair

The 6SE6440-2UD15-5AA1 model is a versatile AC drive from Siemens within the MICROMASTER series. This device utilizes 3-phase AC voltage with an input ranged between 380 and 480 volts. It effectively accommodates input frequencies ranging from 47 to 63 Hz, drawing an input current of 2.8 A in operation.

This unit is capable of outputting a 3-phase AC voltage, adjustable up to the maximum input voltage, and operates efficiently at frequencies spanning from 0 to 650 Hz. It supports output currents of up to 1.6 A, delivering reliable control for applications requiring a motor rated at 0.55 kW.

Designed with a protection rating of IP20, the drive is suitable for internal environments, guarding against dust to some extent. Operationally, it functions effectively in temperature ranges from -10 to 55 degrees Celsius, maintaining performance in diverse conditions. From a humidity perspective, it can withstand up to 80% relative humidity during operation and storage periods, without condensation.

The device is also rated for use at altitudes of up to 1000 meters, further enhancing its adaptability in various settings. Overall, the Siemens 6SE6440-2UD15-5AA1 AC drive offers robust performance tailored for different industrial motor control applications.
