Product image is representative; revision or series may vary. Contact us to request a specific version.
QS2200H
The QS2200H from Siemens is a reliable molded case circuit breaker designed for one-phase applications. It features a rated current of 200 A and operates at a voltage range of 120/240 VAC, providing thermal magnetic protection.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for QS2200H
| Manufacturer | Siemens |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | Q Series |
| Part Number | QS2200H |
| UPC | 783087935310 |
| Mounting Style | Load Center Mount |
| Poles | 2 Poles |
| Rated Current | 200 A |
| Protection Type | Thermal Magnetic |
| Interrupting Rating | 22 kA at 240 V |
| Line/Load Orientation | Fixed |
| Trip Functions | Long-Time, Instantaneous |
| Phase | 1 Phase |
| Rated Voltage | 120/240 VAC |
| Frequency | 60 Hz |
| Connection Type | Plug-in |
Siemens offers the QS2200H molded case circuit breaker as part of its Q Series lineup. This device is engineered for use in single-phase electrical systems. With a rated current capacity of 200 Amperes, it is suitable for various applications where efficient circuit protection is vital. The circuit breaker functions within a voltage range of 120 to 240 VAC.
The QS2200H features a fixed orientation for line and load connections and is equipped with two poles. It employs thermal magnetic protection, ensuring reliable response to overload conditions. This unit is rated for an interrupting capacity of 22 kA at 240 V, providing assurance during fault events.
This circuit breaker includes trip functions for long-time and instantaneous operations, allowing it to cater to diverse protection requirements. The frequency rating for this breaker is 60 Hz, ensuring compatibility with standard electrical systems. Designed to be mounted in load centers, the QS2200H utilizes a plug-in connection type to facilitate straightforward installation.
