ED42B025
The Siemens ED42B025 belongs to the SENTRON series and functions as a molded case circuit breaker. With a significant capacity of 25 amperes and compatibility for 480 VAC systems, this circuit breaker is versatile in demanding environments.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for ED42B025
| Manufacturer | Siemens |
|---|---|
| Product Type | Circuit Breaker |
| Product Line | SENTRON |
| Part Number | ED42B025 |
| UPC | 783643209237 |
| Breaker Type | Molded Case |
| Interrupt Rating at 480V | 18 kA |
| Load Side Terminal | Lug (Included) |
| Mounting | Panel/DIN |
| Trip Type | Thermal Magnetic |
| Amperage | 25 A |
| Poles | 2 Poles |
| Voltage Rating | 480 VAC |
| Maximum Voltage | 600 V |
| Interrupt Rating at 240V | 65 kA |
The Siemens ED42B025 circuit breaker, part of the SENTRON series, is engineered to offer reliable protection and control within electrical systems. Rated for a voltage of 480 VAC, this molded case breaker efficiently handles up to 25 amperes. It is equipped with a thermal magnetic trip mechanism, ensuring effective response to overcurrent situations. This unit comprises two poles, accommodating various circuit configurations.
The breaker's interruption capabilities are prominent, featuring a rating of 18 kA at 480 V and an even higher rating of 65 kA at 240 V. This performance ensures effective protection against potential short circuit conditions. Designed for mounting convenience, it can be easily installed on panels or DIN rails. Additionally, load side terminals are fitted with lugs, simplifying the connection process. The Siemens ED42B025 circuit breaker stands out in environments requiring efficient, dependable circuit management.
