ED63A002
The Siemens ED63A002 is a molded case circuit breaker designed to handle electrical control applications effectively. This unit features a current rating of 2 A and operates on a voltage rating of up to 600 V AC, making it suitable for various industrial environments.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for ED63A002
| Manufacturer | Siemens |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | SENTRON |
| Part Number | ED63A002 |
| UPC | 783643210790 |
| Current Rating | 2 A |
| Number of Poles | 3 Poles |
| Voltage Rating | 600 V AC |
| Trip Type | Magnetic only |
| Interrupting Rating | 5 KAIC at 480 V; 18 KAIC at 600 V |
| Frequency Rating | 50/60 Hz |
| Frame Size | ED Frame |
| Line Side Termination Method | Lug |
| Load Side Termination Method | Lug (included) |
| Wire Range (Copper) | 14–10 AWG |
| Wire Range (Aluminum) | 12–10 AWG |
With the Siemens ED63A002 molded case circuit breaker, reliable circuit protection is ensured in various applications. This model is built with a robust frame size designated as the ED frame, enabling effective installation in diverse environments. Rated for 2 A, it supports a maximum voltage of 600 V AC, accommodating systems that require such capacity.
This unit is constructed with three poles, making it suitable for three-phase applications. Its trip mechanism operates on a magnetic-only basis, providing swift response to overcurrent conditions. The interrupting rating is considerable, providing 5 KAIC when functioning at 480 V and achieving an impressive 18 KAIC rating at 600 V, showcasing its ability to handle substantial fault scenarios.
Operating under a frequency range of 50 to 60 Hz, this circuit breaker employs lugs for both line side and load side terminations. The load side termination lugs are included, ensuring a seamless installation process. Additionally, the ED63A002 can accept copper wires ranging from 14 AWG to 10 AWG, and aluminum wires sized from 12 AWG to 10 AWG, making it versatile for various wiring requirements in electrical applications.
