Product image is representative; revision or series may vary. Contact us to request a specific version.
HED43B030
The HED43B030 circuit breaker from Siemens is a reliable molded case unit designed to protect circuits. It provides a rated current of 30 amperes and operates effectively within a frequency range of 50 to 60 Hz.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for HED43B030
| Manufacturer | Siemens |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | SENTRON |
| Part Number | HED43B030 |
| UPC | 783643210127 |
| Rated Current | 30 A |
| Frame Type | ED Frame |
| Connection Type | Load lug Connection |
| Min. Frequency | 50 Hz |
| Max. Frequency | 60 Hz |
| Number of Poles | 3 Poles |
| Phase Type | 3 Phases |
| Mounting Type | Panel Mount |
| Trip Type | Thermal Magnetic Trip |
| Wire Size | 10 to 1/0 AWG |
| Voltage Rating | 480 VAC |
The Siemens HED43B030 is a molded case circuit breaker designed for versatile application in electrical distribution. It operates with a rated current of 30 Amps, capable of managing 3-phase systems. This unit employs a thermal magnetic trip mechanism, ensuring protection against overload and short-circuit events.
The HED43B030 is constructed on an ED frame structure, which supports durability in various conditions. Its load lug connection type allows for straightforward installation and enhanced electrical contact. This breaker is compatible with wire sizes ranging from 10 AWG to 1/0 AWG, making it flexible for different installation needs. Additionally, it operates efficiently across a frequency spectrum from 50 Hz to 60 Hz, ensuring reliable functionality within common industrial standards. Mounting is designed for panel installation, optimizing space and access in control panels. With a voltage rating of 480 VAC, the HED43B030 is suited for a variety of high-voltage applications, providing dependable circuit protection.
