Siemens SENTRON JXD62B200

Product image is representative; revision or series may vary. Contact us to request a specific version.

JXD62B200

|
Need a Specific Revision?

The Siemens JXD62B200 is a molded case circuit breaker suitable for a range of electrical applications. With a durable design, it handles voltages up to 600 VAC and provides robust circuit protection for single-phase systems.

Call for an immediate quote
2 Year DO Supply Warranty
Available
Ships from Raleigh, NC
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for JXD62B200

ManufacturerSiemens
Product TypeMolded Case Circuit Breaker
Product LineSENTRON
Part NumberJXD62B200
UPC783643212985
Interrupt Rating at 240 VAC65 kA
Interrupt Rating at 480 VAC35 kA
Interrupt Rating at 600 VAC25 kA
Highest DC Voltage30 V
Lowest DC Voltage25 V
Number of Poles2 Poles
Standard Temperature Rating40°C
Terminal ConnectionLoad Side Lugs
Protection TypeThermal Magnetic
Connection TypeBolt-On Type
Frame TypeJXD Frame
Phase Type1-Phase
Request a Repair

The Siemens JXD62B200 molded case circuit breaker is engineered for high reliability in electrical systems. Rated for use in single-phase applications, it supports a highest DC voltage of 30 V and a lowest DC voltage of 25 V. This breaker is recognized for its compact frame type designated as JXD.

The device exhibits impressive interrupt ratings; it handles fault currents with a capacity of 65 kA at 240 VAC, 35 kA at 480 VAC, and 25 kA at 600 VAC, ensuring effective management of short circuit situations. Its thermal magnetic protection type ensures optimal performance under various load conditions.

Designed for straightforward installation, the JXD62B200 utilizes a bolt-on connection method. The terminal connection on the load side is designed for secure and reliable wiring. Operating within a standard temperature rating of 40°C, this circuit breaker is suitable for a broad range of environments, making it a dependable choice for many power distribution systems.
