Product image is representative; revision or series may vary. Contact us to request a specific version.
LD63F600
The Siemens LD63F600 is part of the SENTRON series and serves as a molded case circuit breaker. It supports a substantial rated current of 600 A and operates at both 600 V AC and 500 V DC, making it suitable for a variety of applications.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for LD63F600
| Manufacturer | Siemens |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | SENTRON |
| Part Number | LD63F600 |
| Frame Size | LD Frame |
| Rated Current | 600 A |
| Rated Voltage (AC) | 600 V AC |
| Rated Voltage (DC) | 500 V DC |
| Minimum Frequency | 50 Hz |
| Maximum Frequency | 60 Hz |
| Trip Type | Thermal-Magnetic |
| Interrupt Rating at 240V AC | 65 kA |
| Interrupt Rating at 480V AC | 35 kA |
| Interrupt Rating at 600V AC | 25 kA |
| Mounting Type | Bolt on Mount |
The Siemens LD63F600 is a robust molded case circuit breaker that functions effectively within the SENTRON series. Designed for high-performance environments, it manages a rated current of 600 A and accommodates voltage levels of 600 V AC and 500 V DC. Its frame size is categorized as LD, indicating its construction to handle substantial electrical loads. This breaker operates well across a frequency range of 50 Hz to 60 Hz, which is typical for most commercial and industrial systems.
Protection is enhanced with a thermal-magnetic trip type, ensuring reliable disconnection under overload or short-circuit conditions. The interrupt ratings are impressive, with the unit able to handle up to 65 kA at 240 V AC, 35 kA at 480 V AC, and 25 kA at the maximum voltage of 600 V AC. Such ratings make it suitable for safeguarding critical circuits in demanding applications.
For installation, the LD63F600 utilizes a bolt-on mount, providing secure placement within various panel configurations. Its rugged design and advanced trip mechanism make it a favorable choice for professionals requiring dependable circuit protection in a range of operational scenarios.
