Siemens SIMATIC 6AV6545-0CC10-0AX0

Product image is representative; revision or series may vary. Contact us to request a specific version.

6AV6545-0CC10-0AX0

|
Need a Specific Revision?

The Siemens 6AV6545-0CC10-0AX0 is a robust Human Machine Interface (HMI) panel designed for seamless touch operation. With a resolution of 640 x 480 pixels, the 10.4-inch display provides vibrant color visuals and easy navigation for industrial applications.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for 6AV6545-0CC10-0AX0

ManufacturerSiemens
Product LineSIMATIC
Part Number6AV6545-0CC10-0AX0
Weight12.00 lbs (5.44 kg)
Name of ModuleSIMATIC HMI Panel
Display TypeSTN, Colors
Resolution640 x 480 px
Number of Function Keys0
Alphanumeric KeyboardYes (onscreen)
Rated Voltage Supply24 VDC
Rated Current Consumption900 mA
OperationTouch
Screen Size10.4"
Request a Repair

The Siemens model 6AV6545-0CC10-0AX0 represents a modern approach to HMI technology within the SIMATIC series. This unit comes equipped with a 10.4-inch display that utilizes STN color technology, providing clear and effective visuals for user engagement. The resolution of 640 x 480 pixels ensures that users can access information easily with clarity. This model is designed for user-friendly interaction, employing touch as the primary method of operation.

At a weight of 4.5 kg (approximately 9.92 lbs), the panel is manageable during installation and integration into existing systems. It requires a rated voltage supply of 24 VDC, and it operates efficiently with a current consumption of 900 mA. Offsetting the absence of physical function keys, the HMI panel features an onscreen alphanumeric keyboard, allowing for versatile user input without the clutter of additional hardware. Overall, the 6AV6545-0CC10-0AX0 embodies a blend of functionality and simplicity, making it an optimal choice for various industrial control applications.
