Siemens SIMATIC 6AV6643-0AA01-1AX0

Product image is representative; revision or series may vary. Contact us to request a specific version.

6AV6643-0AA01-1AX0

|
Need a Specific Revision?

Siemens offers the 6AV6643-0AA01-1AX0 as a robust operator interface panel in the SIMATIC series. Featuring a 5.7-inch TFT display with a resolution of 320 x 240 pixels, this panel ensures clear visual interaction and supports touch functionality.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for 6AV6643-0AA01-1AX0

ManufacturerSiemens
Product TypeOperator Interface Panel (TP277)
Product LineSIMATIC
Part Number6AV6643-0AA01-1AX0
UPC662643209563
Weight0.94 lbs (0.43 kg)
Display Technology5.7-inch TFT with touch functionality
Screen Resolution320 x 240 pixels (QVGA)
Color Capability256-color palette
Backlight DurabilityEstimated 60,000-hour lifespan at 25°C
Touch InterfaceResistive analog touch panel
User Storage Capacity4 MB Flash memory
Processing Unit32-bit RISC architecture
Connectivity Ports1x RS422, 1x RS485, 1x Ethernet (RJ45), 1x USB
Supported CommunicationCompatible with PROFINET, PROFIBUS, MODBUS, TCP/IP
Temperature RangeFunctional between 0°C and 50°C
Enclosure ProtectionIP65-rated front panel, IP20 rear panel
Physical Dimensions212 mm (W) x 156 mm (H) x 45 mm (D)
Request a Repair

The Siemens 6AV6643-0AA01-1AX0 is a versatile operator interface panel, known as the TP277, ideal for localized control and monitoring tasks. It comes equipped with a 5.7-inch TFT screen that features a quality resolution of 320 x 240 pixels, delivering sufficient clarity and visibility for operators. With a color capability of 256 hues, the interface offers a straightforward and intuitive user experience.

Durability is emphasized through its backlight, which is rated to last for about 60,000 hours when operating at 25°C. The panel utilizes a resistive analog touch technology for user input, providing responsive interaction with the system. A built-in flash memory capacity of 4 MB offers ample space for user-specific configurations and data.

Powered by a 32-bit RISC architecture, this unit ensures efficient processing for various tasks. Connectivity options are plentiful, featuring ports for RS422, RS485, Ethernet (RJ45), and USB connections. The device supports multiple communication protocols, including PROFINET, PROFIBUS, MODBUS, and TCP/IP, allowing seamless integration into existing industrial networks.

Physical dimensions of the panel measure 212 mm in width, 156 mm in height, and 45 mm in depth, ensuring it fits well in most control environments. Operating efficiently between 0°C and 50°C, it retains functionality in moderate temperature conditions and is protected by an IP65-rated front panel and an IP20-rated rear panel, safeguarding electronics from environmental factors.
