Siemens SIMOTION 6AU1410-2AD00-0AA0

Product image is representative; revision or series may vary. Contact us to request a specific version.

6AU1410-2AD00-0AA0

|
Need a Specific Revision?

The Siemens 6AU1410-2AD00-0AA0 is a drive-based control unit from the SIMOTION series, designed for both single-axis and multi-axis applications. It features various input and output interfaces, including 5 digital input (DI) interfaces and 8 digital input/digital output (DI/DO) interfaces, enhancing its operational versatility.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for 6AU1410-2AD00-0AA0

ManufacturerSiemens
Product LineSIMOTION
Part Number6AU1410-2AD00-0AA0
UPC887621020859
Weight1.00 lbs (0.45 kg)
PartDrive-Based Control Unit
OperationSingle-Axis and Multi-Axis
DI Interfaces5 DI Interfaces
DI/DO Interfaces8 DI/DO Interfaces
F-DI Interfaces3 F-DI Interfaces
F-DO Interfaces1 F-DO Interfaces
AI Interfaces1 AI Interface
Ethernet Port1 Ethernet Port
Operating Temperature0 to 40 degrees Celsius
Storage Temperature0 to 50 degrees Celsius
Maximum Operating Humidity80% RH (non-condensing)
Maximum Storage Humidity80% RH (non-condensing)
Maximum Operating Altitude1000 meters above sea level without derating
PROFIBUS Port1 PROFIBUS Port
PROFINET Ports2 Ports
Request a Repair

The 6AU1410-2AD00-0AA0 from Siemens serves as an advanced drive-based control unit within the SIMOTION series. Its design caters to both single-axis and multi-axis operational needs, making it suitable for various automation applications. This unit is equipped with five DI interfaces, allowing for multiple digital signals to be processed. Additionally, it contains eight DI/DO interfaces for flexibility in handling both inputs and outputs.

For more advanced functions, the control unit includes three F-DI interfaces and one F-DO interface. An analog input capability is provided through a dedicated AI interface. Connectivity is supported via one Ethernet port, which enables communication with other networked devices. Moreover, the device features two PROFINET ports and a single PROFIBUS port, enhancing its integration in modern industrial environments.

The environmental specifications ensure robust operation; with an operating temperature that ranges from 0 to 40 degrees Celsius, the unit remains functional in demanding settings. For storage, it tolerates temperatures from 0 to 50 degrees Celsius, with humidity levels allowed up to 80% (non-condensing) during operation and while stored. This control unit can be used effectively up to an altitude of 1000 meters above sea level without any derating, making it suitable for installations in elevated locations.
