6SL3224-0BE17-5UA0

Designed for flexibility, the Siemens 6SL3224-0BE17-5UA0 from the SINAMICS G120 series serves as a 3-phase inverter. Operating within an input voltage range of 380 to 480 V AC, it maintains performance with a tolerance of ±10%, making it adaptable to various electrical systems. It can efficiently operate with an input frequency of 47 to 63 Hz, typical for industrial electronics.

Providing a rated power capacity of 0.75 kW, this inverter can handle overload conditions up to 150% for 57 seconds, crucial for applications requiring quick bursts of power. Cooling is achieved via internal air circulation, necessitating a cooling air flow of approximately 0.005 m³/s (0.177 ft³/s) to ensure stable operation. The power factor of 0.85 indicates effective utilization of power, while the efficiency rating of 97% demonstrates its capability in minimizing losses, with only 0.10 kW loss during operation.

This unit operates in environments with up to 95% relative humidity and is rated at IP20. Compactly designed for easy integration, it has dimensions of 173 mm (height), 73 mm (width), and 145 mm (depth). With these specifications, the Siemens 6SL3224-0BE17-5UA0 provides reliable performance for controlling motor speeds and various automation processes.
