Siemens SINAMICS G120 6SL3224-0BE31-1AA0

Product image is representative; revision or series may vary. Contact us to request a specific version.

6SL3224-0BE31-1AA0

|
Need a Specific Revision?

The Siemens 6SL3224-0BE31-1AA0 from the SINAMICS G120 series is a versatile drive designed for robust performance. With an input voltage range of 380 to 480 Volts AC and capable of handling a maximum input current of 32.7 Amps, this unit is suitable for various applications requiring reliable motor control.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for 6SL3224-0BE31-1AA0

ManufacturerSiemens
Product LineSINAMICS G120
Part Number6SL3224-0BE31-1AA0
UPC662643434422
Weight6.00 lbs (2.72 kg)
Input Voltage380 to 480 Volts AC
Input Phase3
Input Current32.7 Amps
Output Current26 Amps
Rated Power11 kW / 15 Hp
Power Loss0.396 kW
Fuse35 Amps
Required Cooling Airflow120 CFM
Frame SizeC
Protection RatingIP20
Operating Temperature0 to 50 °C
Storage Temperature-40 to 70 °C
Humidity<95%
Altitude without Derating1000 meters
Request a Repair

The 6SL3224-0BE31-1AA0 drive from Siemens, part of the SINAMICS G120 series, is engineered for demanding industrial applications. It operates on a three-phase input voltage ranging from 380 to 480 Volts AC and draws a maximum input current of 32.7 Amps. This device can deliver an output current of 26 Amps, making it suitable for diverse motor control tasks. With a rated power capacity of 11 kW (15 Hp), this drive provides substantial power handling capabilities.

The power loss associated with this model is rated at 0.396 kW, necessitating a 35 Amp fuse to ensure safe operation. Proper cooling is crucial, as the unit requires an airflow of 120 CFM for optimal performance. Weighing 6.5 kg, it is designated within a C-frame size, suitable for numerous mounting configurations. This drive has a protection rating of IP20, indicating it must be housed in a clean, dry environment.

Operating temperature ranges from 0 to 50 °C, allowing for a broad range of applications. For storage, it can withstand temperatures as low as -40 °C, reaching a maximum of 70 °C, thus providing flexibility in various storage environments. Humidity levels below 95% should be maintained for reliable operation. The drive can be installed at an elevation of up to 1000 meters without loss of performance, ensuring it meets the needs of many operational settings.
