Siemens SINAMICS G120 6SL3224-0BE33-7UA0

Product image is representative; revision or series may vary. Contact us to request a specific version.

6SL3224-0BE33-7UA0

|
Need a Specific Revision?

The 6SL3224-0BE33-7UA0 is a member of Siemens’ SINAMICS G120 series, designed as a compact drive solution. This model operates within an input voltage range of 380 to 480 Volts AC and requires a three-phase supply for optimal performance.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for 6SL3224-0BE33-7UA0

ManufacturerSiemens
Product LineSINAMICS G120
Part Number6SL3224-0BE33-7UA0
UPC662643434538
Weight35.00 lbs (15.88 kg)
Input Voltage380 to 480 Volts AC
Input Phase3
Input Current90 Amps
Output Current75 Amps
Rated Power37 kW / 50 Hp
Power Loss1.2 kW
Fuse125 Amps
Required Cooling Airflow240 CFM
Frame SizeE
Protection RatingIP20
Operating Temperature0 to 50 °C
Storage Temperature-40 to 70 °C
Humidity<95%
Altitude without Derating1000 meters
Request a Repair

Within the SINAMICS G120 range, the Siemens 6SL3224-0BE33-7UA0 model stands out as a versatile drive. This device caters to an input voltage spectrum from 380 to 480 Volts AC and requires a three-phase supply for operation. It draws a current of 90 Amps while delivering a maximum output current of 75 Amps, supporting a rated power output of 37 kW, which equates to 50 Horsepower. The device is also designed with a 125-Amp fuse to enhance its protective features.

The power loss associated with this module is measured at 1.2 kW, indicating efficient energy use, while its cooling requirements stand at 240 CFM. Weighing 16 kg, the unit fits within a frame size classified as E. The protection rating is rated at IP20, safeguarding the internal components from dust and direct contact. This drive operates effectively within a temperature range from 0 to 50 °C, making it suitable for a wide array of applications. It can endure storage temperatures extending from -40 to 70 °C, highlighting its resilience in diverse settings. Additionally, with an operational humidity threshold of less than 95%, this model ensures reliable performance in various environments. Furthermore, it can operate at altitudes of up to 1000 meters without derating, enhancing its adaptability for high-elevation applications.
