Siemens SINAMICS G120 6SL3362-0AG00-0AA1

Product image is representative; revision or series may vary. Contact us to request a specific version.

6SL3362-0AG00-0AA1

|
Need a Specific Revision?

The 6SL3362-0AG00-0AA1 from the Siemens SINAMICS G120 series is designed to operate on 230 Volts AC with a frequency range of 50/60 Hz. It has a maximum input current of 4.28 Amps, ensuring up to 980 W of power consumption.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for 6SL3362-0AG00-0AA1

ManufacturerSiemens
Product LineSINAMICS G120
Part Number6SL3362-0AG00-0AA1
UPC662643068412
Weight22.00 lbs (9.98 kg)
Input Voltage230 Volts AC
Frequency50/60 Hz
Input Current4.28 Amps
Power Consumption980 W
Drive SizeG, H, J
Operating Temperature0 to 50 °C
Storage Temperature-40 to 70 °C
Humidity<95%
Altitude Without Derating1000 meters
EnclosureMetallic
Request a Repair

The Siemens part number 6SL3362-0AG00-0AA1 belongs to the SINAMICS G120 series and serves as a highly efficient drive solution. It works effectively at an input voltage of 230 Volts AC while accepting frequencies of 50 or 60 Hz. The device allows for an input current of 4.28 Amps, making it suitable for various applications requiring a power output up to 980 W.

Built to handle operational conditions, this drive can withstand ambient temperatures ranging from 0 to 50 degrees Celsius, making it versatile for most industrial environments. Regarding storage, it can endure extreme temperatures from -40 to 70 degrees Celsius, ensuring reliable performance even in harsh conditions.

Humidity should remain below 95% for optimal functioning, which is typical for electrical equipment in industrial settings. Additionally, the drive is rated for operation at altitudes up to 1000 meters without experiencing derating, allowing for installation in high-elevation areas. This model is enclosed in a sturdy metallic casing that provides protection against physical damage while ensuring durability.
