6SL3210-1SE21-0AA0

The 6SL3210-1SE21-0AA0 model by Siemens is characterized as a converter power module within the SINAMICS S120 series. It is designed to handle 3-phase AC input voltages from 380 to 480 volts, maintaining a frequency of either 50 or 60 Hz. With a continuous output current capacity of 10.2 A, this power module can deliver an output power rating of 4.0 kW for 3-phase AC applications. Its physical configuration adopts a compact blocksize design, classified under Frame Size FSB, which makes it easy to integrate into various systems.

A notable feature is its integrated line filter, which is installed for compliance with EMC regulations, ensuring that the module operates efficiently without introducing electromagnetic interference. To maintain an effective cooling performance, the unit employs an internal forced-air cooling approach.

Weighing approximately 4 kg, the dimensions are compact at 153 mm wide, 270 mm high, and 165 mm deep, making it suitable for diverse applications without occupying excessive space. The overload capability is rated at 150% for 60 seconds, allowing brief operation under higher loads without compromising performance. It supports control interfaces via PROFIBUS and PROFINET, enhancing connectivity options for various industrial environments. The module can operate between ambient temperatures of 0°C and +40°C without any derating requirements, thus ensuring reliability and stability within specified temperatures.
