Siemens SINAMICS 6SL3040-0MA00-0AA1

Product image is representative; revision or series may vary. Contact us to request a specific version.

6SL3040-0MA00-0AA1

|
Need a Specific Revision?

The 6SL3040-0MA00-0AA1 from Siemens is a CU320 control unit tailored for robust automation tasks. It operates with a nominal supply voltage of 24 V DC and supports an input voltage range between 20.4 and 28.8 V DC.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for 6SL3040-0MA00-0AA1

ManufacturerSiemens
Product TypeCU320 Control Unit
Product LineSINAMICS
Part Number6SL3040-0MA00-0AA1
UPC662643066685
Weight3.00 lbs (1.36 kg)
Input Voltage Range20.4 – 28.8 V DC
Nominal Supply Voltage24 V DC
Base Current Consumption0.8 A
Heat Dissipation20 W
DRIVE-CLiQ Cable Length LimitUp to 100 m
Grounding ConnectionM5/3 Nm screw on housing
Digital I/O Response TimeDepends on evaluation (per diagrams)
Interface TypeDRIVE-CLiQ
Cooling SystemPassive air cooling
Request a Repair

The Siemens 6SL3040-0MA00-0AA1 CU320 control unit is engineered for efficiency in industrial applications. It is designed to operate with a nominal supply voltage of 24 V DC and works effectively within an input voltage range of 20.4 to 28.8 V DC. The base current consumption is recorded at 0.8 A, which is optimal for many control scenarios. The device has been designed to effectively dissipate a heat load of 20 W, ensuring consistent performance during operation.

This control unit employs a DRIVE-CLiQ interface, which facilitates high-speed device communication. It has a cable length limitation of up to 100 meters when connecting with other equipment, making it versatile for various installations. The device weighs approximately 1.5 kg, indicating its lightweight nature for easy integration.

For connections, the unit features a grounding mechanism secured by an M5/3 Nm screw located on the housing, enhancing electrical safety. Digital input/output response times vary based on evaluation per the provided diagrams, allowing for flexibility in integration. Furthermore, the unit utilizes a passive air cooling system, essential for maintaining optimal operating conditions without requiring active cooling components.
