Siemens SIRIUS 3RT1035-1AK60

Product image is representative; revision or series may vary. Contact us to request a specific version.

3RT1035-1AK60

|
Need a Specific Revision?

The Siemens 3RT1035-1AK60 power contactor from the SIRIUS series is engineered for handling heavy loads in a 3-phase electrical system. It has a current rating of 40A and operates at varying voltages of 110, 120, or 400 VAC, making it versatile for different applications.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for 3RT1035-1AK60

ManufacturerSiemens
Product LineSIRIUS
Part Number3RT1035-1AK60
UPC754554411163
Weight1.88 lbs (0.85 kg)
NamePower Contactor
Number of Phases3-phase
Current Rating40A
Voltage Rating110/120/400 VAC
Power Rating18.5 kW
Frequency50/60 Hz
Number of Poles3-pole
Size ClassS2
ConnectionScrew Terminals
Request a Repair

Within the realm of electrical components, the Siemens 3RT1035-1AK60 contactor stands out as a reliable power contactor. Specifically designed for 3-phase configurations, it supports a current capacity of 40A. This contactor can operate across multiple voltage settings, including 110, 120, or 400 VAC, which provides flexibility for various electrical setups.

At a power rating of 18.5 kW, this device can accommodate substantial load requirements while ensuring stable operation across the specified frequency range of 50/60 Hz. The contactor features three poles, offering effective switching capabilities. It adheres to size class S2, which is essential for specific installation constraints.

The design incorporates screw terminals, facilitating secure and intuitive connections. The physical dimensions are compact, measuring 2.441 inches in width by 4.646 inches in height and 4.882 inches in depth, with a weight of 0.84 kg (1.852 lbs.). Such specifications make the 3RT1035-1AK60 suitable for a myriad of applications within electrical control systems.
