3RV1011-1EA10

The Siemens 3RV1011-1EA10 is a circuit breaker that provides essential protection for electrical circuits. Designed to handle an operating voltage range spanning from 20 V to 690 V, it maintains safety even under substantial operational demands. This unit features a significant maximum short-circuit breaking capacity of 100 kA, which is crucial for protecting equipment from faults.

In terms of power loss, the circuit breaker consumes 7.25 W when in a hot state. Each of its three poles contributes a power loss of 2.4 W. The magnetic trip design ensures swift disconnection in the event of a short circuit, enhancing the unit's reliability in unexpected scenarios.

The 3RV1011-1EA10 is suited for various mounting positions, accommodating installation flexibility. It can be fastened using screws and snap-on mechanisms onto a standard 35 mm DIN rail. The dimensions of the breaker are compact, measuring 45 mm wide, 90 mm high, and 75 mm deep, while it is lightweight at just 0.273 kg. Furthermore, this breaker is rated for an insulation voltage of 690 V and can withstand surge voltages up to 6 kV, making it an appropriate choice for diverse industrial applications.
