B32000S07

Siemens has engineered the B32000S07 as part of its SpeedFax series, classifying it as a branch miniature circuit breaker. This compact device is rated for 20 amperes and operates within the voltage parameters of 240 volts AC. Its three-pole configuration makes it suitable for three-phase electrical systems, allowing for balanced load distributions and effective circuit management.

The B32000S07 circuit breaker is capable of withstanding overcurrent with an AIC rating of 10 kA at 240 volts. This robust feature helps protect equipment and maintain operational integrity under fault conditions. Its frame type is designated as BL, which contributes to its overall design and functionality.

Mounting this breaker is straightforward, as it utilizes a bolt-on style. The operational frequency for this device is set at 60 Hz, ensuring compatibility with standard electrical systems. For enhanced protection against overloads, the circuit breaker includes a thermal magnetic trip function, which employs both long-time and instantaneous trip responses automatically.

An additional feature of the B32000S07 includes a shunt trip accessory that functions at 24 volts DC, offering further control integration options within automated systems. This model thus represents a reliable and efficient choice for various branch circuit applications.
