Product image is representative; revision or series may vary. Contact us to request a specific version.
B360H00S01
The Siemens B360H00S01 is a shunt trip circuit breaker designed for reliable operation in 3-phase systems. With a rated current of 60 A, it features a control voltage of 120 V and a notable interrupting capacity of 22 kA at 240 VAC.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for B360H00S01
| Manufacturer | Siemens |
|---|---|
| Product Type | Circuit breaker |
| Product Line | SpeedFax |
| Part Number | B360H00S01 |
| UPC | 783643268999 |
| Circuit Breaker Type | Shunt trip |
| Phase | 3-phase |
| Interrupt Rating | 22 kA at 240 VAC |
| Rated Current | 60 A |
| Actuator Type | Toggle |
| Control Voltage | 120 V |
| Nominal Voltage | 120/240 VAC |
| Protection Type | Thermal magnetic |
| Mounting Type | Bolt-on |
| Poles | 3 poles |
| Application | Panelboard use |
| Terminal Connection | Load side lug |
| Min Wire Size | 8 AWG |
The B360H00S01 from Siemens, belonging to the SpeedFax series, is a specialized circuit breaker tailored for high-use applications. Operating at a rated current of 60 Amps, it is suitable for 3-phase electrical systems. With a nominal voltage of 120/240 VAC, this unit can handle significant loads effectively.
Designed as a shunt trip breaker, it possesses a notable interrupt rating of 22 kA at 240 VAC, providing essential protection during fault conditions. The protective mechanism is classified as thermal magnetic, ensuring efficient response to overloads and short circuits. This circuit breaker also operates at a control voltage of 120 V, facilitating various functional applications.
Installation is straightforward, thanks to the bolt-on mounting configuration. It comprises 3 poles and connects terminals via load side lugs, with a minimum wire size of 8 AWG. This breaker is specifically intended for use in panelboards, allowing for comprehensive circuit management and safety within electrical systems.
