BF260AH
The Siemens BF260AH circuit breaker belongs to the SpeedFax series and operates at 120/240 VAC with an amperage rating of 60 A. This single-phase, two-pole device provides thermal magnetic protection and offers both long-time and instantaneous trip functions.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for BF260AH
| Manufacturer | Siemens |
|---|---|
| Product Type | Circuit Breaker |
| Product Line | SpeedFax |
| Part Number | BF260AH |
| UPC | 887621215484 |
| Phase | Single-phase |
| Number of Poles | 2 Poles |
| Voltage Rating | 120/240 VAC |
| Amperage Rating | 60 A |
| Protection Type | Thermal Magnetic |
| Interrupt Rating | 22 kAIC |
| Residual Current Sensitivity | 5 mA |
| Trip Functions | Long-time, Instantaneous |
| Application | Panelboard Protection |
| Mounting Type | Bolt-on |
| Terminal Connection | Load-side Lug |
| Frequency | 60 Hz |
| Short-Circuit Rating | 22 kA at 240 V |
The Siemens BF260AH is a circuit breaker designed for robust performance and effective protection in panelboard applications. Operating as a single-phase unit, it is structured with two poles and has a voltage rating of 120/240 VAC. The circuit breaker handles an amperage of up to 60 A, making it suitable for various electrical systems.
This device employs thermal magnetic protection, allowing for both long-time and instantaneous trip functions. In terms of safety, the interrupt rating of 22 kAIC and a short-circuit rating at 240 V also at 22 kA ensure that the breaker can withstand significant fault conditions without failure.
Moreover, it includes a residual current sensitivity of 5 mA, providing enhanced protection against ground faults. Installation is simplified with a bolt-on mounting type, and the terminal connection utilizes load-side lugs. Operating at a frequency of 60 Hz, the BF260AH circuit breaker is an essential component in managing and protecting electrical panels.
